Technical Specifications| Engine Engine type Cooling system Displacement Max power Max torque Bore x Stroke Compression ratio Starting system Ignition System Ignition timing Carburetion system Spark Plugs Lubrication System Engine Oil Clutch Type Driving System Transmission Drive System Clutch Type Gear Ratios | 4-stroke, Single Cylinder, SOHC, 2 valves Natural Air Cooled 124.60 cm3 7.83 kw ( 10.65 PS ) @8,500 rpm 9.80 Nm ( 1.0 kg-m ) @ 7,000 rpm 54.0 x 54.4 mm 9.30:1 Kick starter DC Ignition 10° BTDC at 1500 rpm, 37° BTDC @ 3,250 RPM Carburetor, BS26 Champion PRZ9HC/MICO Force Lubrication (Wet Sump) SAE 10W-40 (1.1 liters) Centrifugal Chain Drive 5-speed, constant mesh, return shift Chain Wet, Multi Disc 1st 33.09:1 (36/11) 2nd 20.22:1 (32/16) 3rd 14.90:1 (28/19) 4th 11.95:1 (26/22) 5th 10.11:1 (24/24) |
| Dimension Overall height Overall length Overall width Kerb weight Seat height Wheelbase Ground clearance Frame type Suspension (front) Suspension (rear) Tire (front) Tire (rear) Inflation (front) Inflation (rear) Fuel tank capacity Battery | 1,115 mm 1,960 mm 740 mm 121 kg 775 mm 1,260 mm 155 mm Tubular, Semi-Double Cradle Ceriant Type : Telescopic, Stroke = 110 mm Trailing Arm with Coaxial Shockabsorbers 2.75 x 18, 4 / 6 PR or 2.75 x 18, 42P (Zapper) 3.00 x 18, 4 / 6 PR (Zapper) 1.75 kg /cm2 ( 25psi ) 2.00 kg / cm2 ( 28 psi ) 13.0 liters 12 V-2.5 Ah |
Source:
http://www.kawasaki.ph
