Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Intake system Spark plug Battery Gear ratios | Air-Cooled, 4-Stroke single cylinder OHC 50.0 x 52.0 mm 102 cc - valves per cylinder 9.0:1 7.0 bhp (5.22 kW) @ 7000 rp 7.85 Nm @ 5000rpm Automatic CVT Dry, Automatic Centrifugal Clutch CDI Electric and kick starter 12V-5Ah |
Dimensions Frame type Rake Overall length Overall width Overall height Wheelbase Seat height Ground clearance Kerb weight Fuel capacity Colors Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | 1750 mm 705 mm 1100 mm 1240 mm 770 mm 125 mm 104 kg 5 litres Bottom Link with Spring-loaded Hydraulic damper Swing Arm with Spring-loaded Hydraulic damper 3.50 x 10 - 4 PR / 51 J 3.50 x 10 - 4 PR / 51 J Internal Expanding Shoe Type (130 mm) Internal Expanding Shoe Type (130 mm) |
